1R1G1B / SMD1515 P1.923 Indoor Full color LED Display HD LED Display
P1.923 Indoor Full color LED Display Specification
| Product Name | Specification | ||||||||||
| Pixel Pitch | 1.923mm | ||||||||||
| Pixel Configuration | 1R1G1B/SMD1515 Black lamp | ||||||||||
| Density | 270,410 pixel/m2 | ||||||||||
| Moduel Size(L×W)mm | 200mm×150mm | ||||||||||
| Cabinet Size(L×W×H)mm | 400mm×300mm×65mm | ||||||||||
| Module Resolution | 104×78 | ||||||||||
| Cabinet Resolution | 208×156 | ||||||||||
| Driving Method | 1/26 Scan | ||||||||||
| Driving IC | MBI5153 | ||||||||||
| Brightness | 600CD/㎡ | ||||||||||
| Contrast | 1000:1 | ||||||||||
| Brightness Adjustment | Auto and Manual | ||||||||||
| Power Consumption | Max Power:＜1000W | ||||||||||
| Average power: ＜450W | |||||||||||
| Module Weight | 0.15kg | ||||||||||
| Color Temperature | 9500K—11500K | ||||||||||
| Horizontal Viewing Angle | 140º | ||||||||||
| Vertical Viewing Angle | 140º | ||||||||||
| Signal Processing | 10 or 14bit | ||||||||||
| Grey Processing | 1024×1024×1024 16834×16834×16834 | ||||||||||
| Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| Frame Frequency | 65 Hz | ||||||||||
| Refresh Rate | >3840Hz | ||||||||||
| Control Mode | Synchronous/Asynchronous | ||||||||||
| The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| MTBF | >50000 hours | ||||||||||
| Life Span | 100,000 Hours | ||||||||||
| Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| Storage : -40 - 85 ℃ | |||||||||||
| Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
| Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
| Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| Power Supply | AC 85-264V | ||||||||||
| Protection Level | IP 41 | ||||||||||
|
|
