    Commercial Advertising P16 Outdoor Full Color Led Display 3906 Pixel/M2


    commercial advertising P16 Outdoor Full color LED Display


    Description:


    Wide application field & short ROI time:
    commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media, shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen, air port LED display screen, telecommunication LED display screen system for information showing and instructio


    Clear vivid image quality:
    Even in direct, full-on sunlight to ensure you attract more audience to get short ROI of your LED display screen's investment.::


    P16 Outdoor Full color LED Display Specification


    NO:Product NameSpecification
    1Pixel Pitch16mm
    2Pixel Configuration1R1G1B/DIP 546
    3Density3,906 pixel/m2
    4Moduel Size(L×W)mm256mm×256mm
    5Cabinet Size(L×W×H)mm1024mm×1024mm×130mm
    6Module Resolution16×16
    7Cabinet Resolution64×64
    8Driving MethodStatic
    9Driving ICMBI5124
    10Brightness8500cd/㎡
    11Contrast1000:1
    12Brightness AdjustmentAuto and Manual
    13Power ConsumptionMax Power: <1200W
    14Average power: <550W
    15Module Weight0.8kg
    16Color Temperature9500K—11500K
    17Horizontal Viewing Angle140º
    18Vertical Viewing Angle140º
    19Signal Processing10 or 14bit
    20Grey Processing1024×1024×1024
    16834×16834×16834
    21Control Distancecable100m,Multimode500m,Single mode 2km
    22Frame Frequency65 Hz
    23Refresh Rate>1920Hz
    24Control ModeSynchronous/Asynchronous
    25The Opposite Calibration CurveWith Eight Optional Gamma Calibration Curve
    26Users can choose the recommended curve or adjust it based on actual situation
    27MTBF>50000 hours
    28Life Span100,000 Hours
    29Operating TemperatureWorking : -20 - 65 ℃
    30Storage : -40 - 85 ℃
    31Environment Temperature-30℃ to 60℃; humidity Rh10% to 95%
    32Remote ControlCan realize remote control and send alarm signal to operators in case of logging failure (Be customized)
    33Self-checking TechniqueSelf-inspection, communication test, power test, temperature monitoring (Be customized)
    34Operating System PlatformWindowsNT,Windows2000,WindowsXP,Windows7
    35Power SupplyAC 110-220V
    36Protectionwaterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)

    Products exchanged or returned :


    we supply our products strictly according to the contract list , if the quantity or specification doesn't meet our contract list, the buyer can give objections within 3 days after received the products , we’ll exchanged after company confirmed.


    Casual damage situation:


    We can provide corresponding fittings without extra fee when improper operation or unexpected artificial damaged arise .


    Over Guarantee time :


    You only have to pay maintenance cost such as labor costs , spare parts costs and round-trip costs !
