    P8 Outdoor Full color LED Display

    Ask Lasest Price
    Brand Name : Vegoo
    Model Number : VG-FD P10
    Certification : CE/ROHS/FCC/
    Supply Ability : 3000Sq.m
    Delivery Time : 3-5 days
    • Product Details
    • Company Profile

    P8 Outdoor Full color LED Display

    Description:


    1. multi-purpose LED Outdoor curtain ideal for outdoor applications

    2. Adjustable single pixel modules allow for creative designs and applications

    3. Carbon Fiber materials guarantee its super thin and lightweight profile


    Applicantion:


    Video, graphics, animation, sports,advertising, entertainment,stage,events,stadium,train station,bus station,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc

    Protection
    waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)

    P8 Outdoor Full color LED Display Specification


    NO:Product NameSpecification
    1Pixel Pitch8mm
    2Pixel Configuration1R1G1B/SMD3535
    3Density15,625 pixel/m2
    4Moduel Size(L×W)mm256mm×128mm
    5Cabinet Size(L×W×H)mm768mm×768mm×130mm
    6Module Resolution32×16
    7Cabinet Resolution96×96
    8Driving Method1/ 4 Scan
    9Driving ICMBI5124 or ICN 2038S
    10Brightness5000cd/㎡
    11Contrast1000:1
    12Brightness AdjustmentAuto and Manual
    13Power ConsumptionMax Power:450W
    14Average power: <200W
    15Module Weight0.35kg
    16Color Temperature9500K—11500K
    17Horizontal Viewing Angle140º
    18Vertical Viewing Angle140º
    19Signal Processing10 or 14bit
    20Grey Processing1024×1024×1024
    16834×16834×16834
    21Control Distancecable100m,Multimode500m,Single mode 2km
    22Frame Frequency65 Hz
    23Refresh Rate>1920Hz
    24Control ModeSynchronous/Asynchronous
    25The Opposite Calibration CurveWith Eight Optional Gamma Calibration Curve
    26Users can choose the recommended curve or adjust it based on actual situation
    27MTBF>50000 hours
    28Life Span100,000 Hours
    29Operating TemperatureWorking : -20 - 65 ℃
    30Storage : -40 - 85 ℃
    31Environment Temperature-30℃ to 60℃; humidity Rh10% to 95%
    32Remote ControlCan realize remote control and send alarm signal to operators in case of logging failure (Be customized)
    33Self-checking TechniqueSelf-inspection, communication test, power test, temperature monitoring (Be customized)
    34Operating System PlatformWindowsNT,Windows2000,WindowsXP,Windows7
    35Power SupplyAC 110-220V
    36Protectionwaterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)


    The Selection of led


    Red,Green and Blue light emitting diode (LED) lamps should be the same grade, height and wavelength on the same displayThe height or Red ,Green and Blue light from light emitting diode(LED ) lamps at the proportion of R:G:B=3:6:1The chips were imported from Optotech Cree/ Nichia are adopted;Adopted automation solid crystal,light split,bonding wire,bagging;
