    High Brightness Seamless Indoor Full Color LED Display Screen P5 Led Video Wall

    Ask Lasest Price
    Brand Name : Vegoo
    Model Number : VG-FD 3
    Certification : CE/ROHS/FCC/
    Supply Ability : 3000 Sq.m / month
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    High Brightness Seamless Indoor Full Color LED Display Screen P5 Led Video Wall


    High brightness seamless SMD2121 1R1G1B P5 Indoor Full color LED Display


    Quick Detail:


    Indoor Full Color LED Display Features:

    1. Relatively low cost;

    2. Stable capability;

    3. Low energy consumption;

    4. Good after-sale


    Description:


    P5 seamless indoor led screens
    1) Relatively low cost
    2) Stable capability
    3) High brightness
    4) Satisfactory after-sales


    P5 Indoor Full color LED Display Specification:


    Product NameSpecification
    Pixel Pitch5mm
    Pixel Configuration1R1G1B/SMD2121 Black lamp
    Density40,000 pixel/m2
    Moduel Size(L×W)mm320mm×160mm
    Cabinet Size(L×W×H)mm640mm×640mm×90mm
    Module Resolution64×32
    Cabinet Resolution128×128
    Driving Method1/16 Scan
    Driving ICMBI5124
    Brightness600CD/㎡
    Contrast1000:1
    Brightness AdjustmentAuto and Manual
    Power ConsumptionMax Power:<500W
    Average power: <200W
    Module Weight0.45kg
    Color Temperature9500K—11500K
    Horizontal Viewing Angle140º
    Vertical Viewing Angle140º
    Signal Processing10 or 14bit
    Grey Processing1024×1024×1024
    16834×16834×16834
    Control Distancecable100m,Multimode500m,Single mode 2km
    Frame Frequency65 Hz
    Refresh Rate>1920Hz
    Control ModeSynchronous/Asynchronous
    The Opposite Calibration CurveWith Eight Optional Gamma Calibration Curve
    Users can choose the recommended curve or adjust it based on actual situation
    MTBF>50000 hours
    Life Span100,000 Hours
    Operating TemperatureWorking : -20 - 65 ℃
    Storage : -40 - 85 ℃
    Environment Temperature-30℃ to 60℃; humidity Rh10% to 95%
    Remote ControlCan realize remote control and send alarm signal to operators in case of logging failure (Be customized)
    Self-checking TechniqueSelf-inspection, communication test, power test, temperature monitoring (Be customized)
    Operating System PlatformWindowsNT,Windows2000,WindowsXP,Windows7
    Power SupplyAC 110-220V
    Protectiondustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)

    High Brightness Seamless Indoor Full Color LED Display Screen P5 Led Video Wall


    Services Before-sale:

    • Set a special telephone line to resolve the confusion from clients and supply free technology services by telephone.
    • Consider the demands of clients carefully , study the situation of the installation condition , Team up the related staff and workers promptly , give clients design program details to help them choose the products which they wanted as soon as possible

    Service In - sales :

    • Try the best to meet the reasonable demands by clients Provisional changed .
    • Keep close touch with the clients during the period if installation .
    • Cooperate friendly with the clients, satisfy the clients with the best quality of led display .

    Service After-sale:

    • Normal products have one year guarantee, and whole life maintenance, free charges . we just charge materials cost only if products out off guarantee.
    • You can down load and upgrade the related operating software of Led display freely from our company website , so as to resolve the problems when you use our led display .
    • Check the quality of appliance , do maintenance job and ask good suggestions form clients on a regular time schedule .

    Customer Service

    1) Guarantee Time: Within one year after delivery form factory

    2) Maintenance Coverage : LED modules,Power supply ,Control system and other accessories ( This warranty exclude accessories purchasing form other factory )

    3) Maintenance Mode :

    By returned maintenance , through express or by other way

    4) Response time for maintenance :

    • Return mode: after receiving the returned products, we will repaired them within 24 hours and send them back to the user;
    • Telephone or internet mode: we will contact user within 2 hours after getting informations and give solution within 8 hours;
    • On-site mode: ( only for user inside china ) after receiving maintenance request , we will respond within 48 hours to user in Guangdong province; 72 hours to user outside Guangdong province, In the case of some special conditions , problems could be solved on the basis of friendly negotiation between two parties.

    Upgrade Service :


    Unschedule, we will upgrade our system of products without extra formal; we’ll do our best to help users with upgrading ; the following conditions are excluded by this warranty :

    • Without approved documents;
    • Series code on products having been torn or changed ;
    • Damage caused by lighting strike or electrical problems;
    • Risks caused by irresistible incidents includes all kinds of natural disasters, fire, wars, policy changes, and some other human error accidents.
    • Users or third party refit or repaired by themselves without VEGOO’s permission ;
    • Water intrusion or corrosion caused by improper keeping or operating ;
    • Over period of free maintenance .
