    MBI5124 / ICN 2038S P4 Led Full Color Display Custom Led Signs Indoor 1000cd/㎡

    Ask Lasest Price
    Brand Name : Vegoo
    Model Number : VG-FD 3
    Certification : CE/ROHS/FCC/
    Supply Ability : 3000 Sq.m / month
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    MBI5124 / ICN 2038S P4 Led Full Color Display Custom Led Signs Indoor 1000cd/㎡


    MBI5124 or ICN 2038S P4 Indoor Full color LED Display 256mm×128mm


    Description:


    1: Aluminum cabinet made by CNC has more accurate tolerance on structure than that made by metalplate processing, which ensures the flatness of the entire LED screen.


    2: Adopting modular design, assembled cabinet can install and disassembly quickly and easily. It is easy to maintenance.


    3. New structure design, can satisfy hoisting, overstow, indoor used requirements. Cabinet simplification.


    4: Has excellent heat dissipation design and performance. it is low noise and doesn't need external fan or air-condition. With the features of lightweight and low power consumption, it can reduce the labor cost of installation and operating costs.


    P4 Indoor Full color LED Display Specification:


    Product NameSpecification
    Pixel Pitch4mm
    Pixel Configuration1R1G1B/SMD2121 Black lamp
    Density62,500 pixel/m2
    Moduel Size(L×W)mm256mm×128mm
    Cabinet Size(L×W×H)mm512mm×512mm×90mm
    Module Resolution64×32
    Cabinet Resolution128×128
    Driving Method1/16 Scan
    Driving ICMBI5124 or ICN 2038S
    Brightness1000cd/㎡
    Contrast1000:1
    Brightness AdjustmentAuto and Manual
    Power ConsumptionMax Power:<610W
    Average power: <240W
    Module Weight0.2kg
    Color Temperature9500K—11500K
    Horizontal Viewing Angle140º
    Vertical Viewing Angle140º
    Signal Processing10 or 14bit
    Grey Processing1024×1024×1024
    16834×16834×16834
    Control Distancecable100m,Multimode500m,Single mode 2km
    Frame Frequency65 Hz
    Refresh Rate>1920Hz
    Control ModeSynchronous/Asynchronous
    The Opposite Calibration CurveWith Eight Optional Gamma Calibration Curve
    Users can choose the recommended curve or adjust it based on actual situation
    MTBF>50000 hours
    Life Span100,000 Hours
    Operating TemperatureWorking : -20 - 65 ℃
    Storage : -40 - 85 ℃
    Environment Temperature-30℃ to 60℃; humidity Rh10% to 95%
    Remote ControlCan realize remote control and send alarm signal to operators in case of logging failure (Be customized)
    Self-checking TechniqueSelf-inspection, communication test, power test, temperature monitoring (Be customized)
    Operating System PlatformWindowsNT,Windows2000,WindowsXP,Windows7
    Power SupplyAC 110–220V


    Protection


    dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)


    MBI5124 / ICN 2038S P4 Led Full Color Display Custom Led Signs Indoor 1000cd/㎡
