    Waterproof 20mm Outdoor Transparent Led Display Full Color 5500CD/㎡

    Ask Lasest Price
    Brand Name : Vegoo
    Model Number : VG-SD P20
    Certification : CE/ROHS/FCC/
    Supply Ability : 3000 Sq.m/ Month
    Delivery Time : 20-25 working days
    • Product Details
    • Company Profile

    Waterproof 20mm Outdoor Transparent Led Display Full Color 5500CD/㎡

    P20 DIP 346 Outdoor Full color LED Display


    Description:


    1. Outdoor advertising LED display
    2. High brightness,stable,durable
    3. Waterproof,IP65
    4. CE,RoHS,FCC certificate


    P20 DIP 346 Outdoor Full color LED Display Specification


    NO:Product NameSpecification
    1Pixel Pitch20mm
    2Pixel Configuration1R1G1B/DIP 346
    3Density2,500 pixel/m2
    4Moduel Size(L×W)mm960mm×17mm
    5Cabinet Size(L×W×H)mm960mm×320mm×90mm
    6Module Resolution48×0.85
    7Cabinet Resolution48×16
    8Driving Method1 Scan
    9Driving ICMBI5124
    10Brightness5500CD/㎡
    11Contrast1000:1
    12Brightness AdjustmentAuto and Manual
    13Power ConsumptionMax Power: <600W
    14Average power: <450W
    15Cabinet Weight18kg
    16Color Temperature9500K—11500K
    17Horizontal Viewing Angle140º
    18Vertical Viewing Angle140º
    19Signal Processing10 or 14bit
    20Grey Processing1024×1024×1024
    16834×16834×16834
    21Control Distancecable100m,Multimode500m,Single mode 2km
    22Frame Frequency65 Hz
    23Refresh Rate>1920Hz
    24Control ModeSynchronous/Asynchronous
    25The Opposite Calibration CurveWith Eight Optional Gamma Calibration Curve
    26Users can choose the recommended curve or adjust it based on actual situation
    27MTBF>50000 hours
    28Life Span100,000 Hours
    29Operating TemperatureWorking : -20 - 65 ℃
    30Storage : -40 - 85 ℃
    31Environment Temperature-30℃ to 60℃; humidity Rh10% to 95%
    32Remote ControlCan realize remote control and send alarm signal to operators in case of logging failure (Be customized)
    33Self-checking TechniqueSelf-inspection, communication test, power test, temperature monitoring (Be customized)
    34Operating System PlatformWindowsNT,Windows2000,WindowsXP,Windows7
    35Power SupplyAC 110-220V
    36Protectionwaterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)

    Perfect service after sale :

    1) Guidance service: We can guide on line if customers have questions about the installation and usage.

    For large project, we provide your engineer a week free training, or if customer could bear the relevant cost, our engineer can go to customer’s country for on-site guidance.

    2) Warranty period: 3 years after shipment.

    3) Maintenance principles: response in time, solve problems as soon as possible and ensure the use.

    4) Maintenance terms: In the Maintenance period, free of all maintenance charges. Under normal use and storage, our company will be responsible for the equipments. If there is any failure in product quality, our company will maintain and change the components for free. After Maintenance period, only charge the material costs fees free of manual work fees.
