    1R1G1B / SMD3535 P6.67 Outdoor Advertising LED Display 22545 Pixel/M2

    Ask Lasest Price
    Brand Name : Vgeoo
    Model Number : VG-RD P6.67
    Certification : Ce/ROHS/FCC/
    Delivery Time : 7 days
    • Product Details
    • Company Profile

    1R1G1B / SMD3535 P6.67 Outdoor Advertising LED Display 22545 Pixel/M2


    1R1G1B/SMD3535 P6.67 Outdoor Full color LED Display


    ​Description:


    • Super Stability
    • High quality components and elaborate processing craft, effectively reducing the blind spot rate even working under the severe environment;
    • Exquisite and tastful appearance due to structural wire layout;
    • Good price
    • Our price is 10% lower than the market because of the introduction of full
    • Automatic production line with the characteristics of reducing the cost of
    • Labor and management;
    • Ideal parameter setting,effectively slowing down the speed of brightness and color reduction;
    • Easy for installation;
    • MTBF: More than 100, 000hours;

    P6.67 Outdoor Full color LED Display Specification


    Product NameSpecification
    Pixel Pitch6.67mm
    Pixel Configuration1R1G1B/SMD3535
    Density22,545 pixel/m2
    Moduel Size(L×W)mm320mm×160mm
    Cabinet Size(L×W×H)mm640mm×640mm×90mm
    Module Resolution48×24
    Cabinet Resolution96×96
    Driving Method1/6 Scan
    Driving ICMBI5124
    Brightness5500cd/㎡
    Contrast1000:1
    Brightness AdjustmentAuto and Manual
    Power ConsumptionMax Power:<800W
    Average power: <400W
    Module Weight0.5kg
    Color Temperature9500K—11500K
    Horizontal Viewing Angle140º
    Vertical Viewing Angle140º
    Signal Processing10 or 14bit
    Grey Processing1024×1024×1024
    16834×16834×16834
    Control Distancecable100m,Multimode500m,Single mode 2km
    Frame Frequency65 Hz
    Refresh Rate>1920Hz
    Control ModeSynchronous/Asynchronous
    The Opposite Calibration CurveWith Eight Optional Gamma Calibration Curve
    Users can choose the recommended curve or adjust it based on actual situation
    MTBF>50000 hours
    Life Span100,000 Hours
    Operating TemperatureWorking : -20 - 65 ℃
    Storage : -40 - 85 ℃
    Environment Temperature-30℃ to 60℃; humidity Rh10% to 95%
    Remote ControlCan realize remote control and send alarm signal to operators in case of logging failure (Be customized)
    Self-checking TechniqueSelf-inspection, communication test, power test, temperature monitoring (Be customized)
    Operating System PlatformWindowsNT,Windows2000,WindowsXP,Windows7
    Power SupplyAC 110-220V
    Protectionwaterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)

    1R1G1B / SMD3535 P6.67 Outdoor Advertising LED Display 22545 Pixel/M2


    Application Areas :


    ·--- Outdoor advertising, digital billboards, advertising in big companies

    ·--- Sports halls, fields, playgrounds.

    ·--- Airports, bus stations and railway passenger terminals.

    ·--- Facades of shopping malls, department stores, banks and car dealerships.

    ·--- Architecture and social projects, information systems in cities.

    ·--- Show-business, concerts, festivals, motor shows and other public events.
