    Outdoor Full Color 1R1G1B SMD2727 Pole LED Display 6000cd/㎡ 320mm×160mm

    Ask Lasest Price
    Brand Name : Vegoo
    Model Number : VG-SD P5
    Certification : CE/ROHS/FCC/
    Delivery Time : 10 days
    • Product Details
    • Company Profile

    Outdoor Full Color 1R1G1B SMD2727 Pole LED Display 6000cd/㎡ 320mm×160mm

    Long lifetime Pole LED Display 1R1G1B/SMD2727 320mm×160mm


    Description:


    ♦ Long lifetime: Adopting high quality LED lamps as core material and patent PCB design for the screen, it essentially ensures long lifetime fo the product.
    ♦Wide view angle: Highly wavelength consistency of LED lamp and 140°horizontal and vertical view angles guarantee viewers can see the playing miages from any direction in front.
    ♦ Stable performanve: we make a spceial treatment of anti-electromagnetic wave and adopt distribution scan and modular design for the screen and it works more reliable and stables.
    ♦ Exquisite images:Nonlinearity correction technology makes the images exquisite clear, video images vivid and fidelity.
    ♦ Excellent flatness: percision design of module frame parts controls the deviation of beighbouring modules within 0.1mm and it has an excellent flatness without mosaic..
    ♦ High contrast:consistend deep black patent masks and black face lamps make the contrast higher and the color fresher.


    Self-checking Technique
    Self-inspection, communication test, power test, temperature monitoring (Be customized)

    P5 Outdoor Full color LED Display Specification


    Product NameSpecification
    Pixel Pitch5mm
    Pixel Configuration1R1G1B/SMD2727
    Density40,000 pixel/m2
    Moduel Size(L×W)mm320mm×160mm
    Cabinet Size(L×W×H)mm960mm×960mm×130mm
    Module Resolution64×32
    Cabinet Resolution192×192
    Driving Method1/8 Scan
    Driving ICMBI5124 or ICN 2038S
    Brightness6000cd/㎡
    Contrast1000:1
    Brightness AdjustmentAuto and Manual
    Power ConsumptionMax Power:<750W
    Average power: <225W
    Module Weight0.28kg
    Color Temperature9500K—11500K
    Horizontal Viewing Angle140º
    Vertical Viewing Angle140º
    Signal Processing10 or 14bit
    Grey Processing1024×1024×1024
    16834×16834×16834
    Control Distancecable100m,Multimode500m,Single mode 2km
    Frame Frequency65 Hz
    Refresh Rate>1920Hz
    Control ModeSynchronous/Asynchronous
    The Opposite Calibration CurveWith Eight Optional Gamma Calibration Curve
    Users can choose the recommended curve or adjust it based on actual situation
    MTBF>50000 hours
    Life Span100,000 Hours
    Operating TemperatureWorking : -20 - 65 ℃
    Storage : -40 - 85 ℃
    Environment Temperature-30℃ to 60℃; humidity Rh10% to 95%
    Operating System PlatformWindowsNT,Windows2000,WindowsXP,Windows7
    Power SupplyAC 85-264V

    Remote Control
    Can realize remote control and send alarm signal to operators in case of logging failure (Be customized)

    The Selection of led


    Red,Green and Blue light emitting diode (LED) lamps should be the same grade, height and wavelength on the same displayThe height or Red ,Green and Blue light from light emitting diode(LED ) lamps at the proportion of R:G:B=3:6:1The chips were imported from Optotech Cree/ Nichia are adopted;Adopted automation solid crystal,light split,bonding wire,bagging;


    Reliability Test


    In order to avoid the potential defects caused in the design and production , we conduct a series of reliability test such as the electronic performance test for the semi-finished products , the anti dust test, the waterproof test , the anticorrosion test( salty spraying test ), the vibration test and thermal shock tester etc. The reliability test for the semi-finished products: Before gluing semi-finished modules , more than 48 hours aging should be made in the high temperature for all the modules , After QC inspection ok then can package itThe reliability test for the finished products.: After assembling finished modules to the led cabinets and simulating the assembly for the whole cabinets , we keep them aging for more than 72 hours , if no defects found , then we will delivery goods to our customers .The waterproof test : During the rainy seasons , the waterproof performance for the outdoor led display is quite important. the performs high-press water spraying as well as against the front cabinet to ensure, if waterproof test in good conditions , therefore , protection rate can reach IP65The anti corrosion test : In order to ensure the reliability of anti corrosion of the PCB and cabinet , hence the salty spraying test must be made during the productions Vibration test : For different kind of screens , in order to ensure the reliability of transportation and moving , therefore , the simulated vibration test must be conducted .The environment test : The real outdoor environment can ensure the effects of display in factory are the same as the spot effects
