    Large Viewing Angle P8 Outdoor Full Color LED Display Refresh Rate 1920Hz

    Ask Lasest Price
    Brand Name : Vegoo
    Model Number : VG-FD P10
    Certification : CE/ROHS/FCC/
    Supply Ability : 3000Sq.m
    Delivery Time : 3-5 days
    • Product Details
    • Company Profile

    Large Viewing Angle P8 Outdoor Full Color LED Display Refresh Rate 1920Hz


    Large viewing angle P8 Outdoor Full color LED Display 320mm×160mm


    Description:


    1. The raw material of all of the outdoor products including LED chips, mask, glue and steel cabinets have the ability of enduring high temperature and high humidity, and being anti-UV, waterproof, anticorrosion and antirust.


    2. Every production process is well controlled and all of the electronic components are covered by 2mm Tri-Guard Lacquer to ensure no oxidation, no rusty and no moisture. Five-Guard Lacquer will be used for special requirements.


    3. Large viewing angle, up to 140°horizontally and 140°vertically, with no image distortion and no color cast at any angle within this range.

    P8 Outdoor Full color LED Display Specification


    Product NameSpecification
    Pixel Pitch8mm
    Pixel Configuration1R1G1B/SMD3535
    Density15,625 pixel/m2
    Moduel Size(L×W)mm320mm×160mm
    Cabinet Size(L×W×H)mm960mm×960mm×130mm
    Module Resolution40×20
    Cabinet Resolution120×120
    Driving Method1/ 5 Scan
    Driving ICMBI5124 or ICN 2038S
    Brightness5500/㎡
    Contrast1000:1
    Brightness AdjustmentAuto and Manual
    Power ConsumptionMax Power:600W
    Average power: <250W
    Module Weight0.6kg
    Color Temperature9500K—11500K
    Horizontal Viewing Angle140º
    Vertical Viewing Angle140º
    Signal Processing10 or 14bit
    Frame Frequency65 Hz
    Refresh Rate>1920Hz
    Control ModeSynchronous/Asynchronous
    Life Span100,000 Hours
    Operating TemperatureWorking : -20 - 65 ℃
    Storage : -40 - 85 ℃
    Environment Temperature-30℃ to 60℃; humidity Rh10% to 95%
    Remote ControlCan realize remote control and send alarm signal to operators in case of logging failure (Be customized)
    Self-checking TechniqueSelf-inspection, communication test, power test, temperature monitoring (Be customized)
    Operating System PlatformWindowsNT,Windows2000,WindowsXP,Windows7
    Power SupplyAC 85-264V
    Protectionwaterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)



    Customer Service


    1) Guarantee Time: Within one year after delivery form factory

    2) Maintenance Coverage : LED modules,Power supply ,Control system and other accessories ( This warranty exclude accessories purchasing form other factory )

    3) Maintenance Mode :

    By returned maintenance , through express or by other way

    4) Response time for maintenance :


    1. Return mode: after receiving the returned products, we will repaired them within 24 hours and send them back to the user;


    2. Telephone or internet mode: we will contact user within 2 hours after getting informations and give solution within 8 hours;


    3. On-site mode: ( only for user inside china ) after receiving maintenance request , we will respond within 48 hours to user in Guangdong province; 72 hours to user outside Guangdong province, In the case of some special conditions , problems could be solved on the basis of friendly negotiation between two parties.


    Upgrade Service :


    Unschedule,we will upgrade our system of products without extra formal; we’ll do our best to help users with upgrading ; the following conditions are excluded by this warranty :

    1. Without approved documents;

    2. Series code on products having been torn or changed ;

    3. Damage caused by lighting strike or electrical problems;

    4. Risks caused by irresistible incidents includes all kinds of natural disasters, fire, wars, policy changes, and some other human error accidents.

    5. Users or third party refit or repaired by themselves without VEGOO’s permission ;

    6. Water intrusion or corrosion caused by improper keeping or operating ;

    7. Over period of free maintenance .
