    Higher Refresh Rate P8 Outdoor Full Color LED Display Led Digital Signage

    Ask Lasest Price
    Brand Name : Vegoo
    Model Number : VG-FD P10
    Certification : CE/ROHS/FCC/
    Supply Ability : 3000Sq.m
    Delivery Time : 3-5 days
    • Product Details
    • Company Profile

    Higher Refresh Rate P8 Outdoor Full Color LED Display Led Digital Signage


    Higher refresh rate P8 Outdoor Full color LED Display


    Description:


    1. Higher refresh rate
    high refresh function for all-weather application, it can avoid the ripple when the camera towards it, it will present a clear/ exquisite image to audience.

    2. Durable material
    This series adopt carbon fiber cabinet. The material is durable for lomg time use under different environment.

    3. Fast assembly and maintenance
    Easy, quick and flexible installation for fast assembly and maintenance,suitable for different applications and uses.


    P8 Outdoor Full color LED Display Specification


    Product NameSpecification
    Pixel Pitch8mm
    Pixel Configuration1R1G1B/SMD3535
    Density15,625 pixel/m2
    Moduel Size(L×W)mm256mm×128mm
    Cabinet Size(L×W×H)mm768mm×768mm×130mm
    Module Resolution32×16
    Cabinet Resolution96×96
    Driving Method1/ 4 Scan
    Driving ICMBI5124 or ICN 2038S
    Brightness5000cd/㎡
    Contrast1000:1
    Brightness AdjustmentAuto and Manual
    Power ConsumptionMax Power:450W
    Average power: <200W
    Module Weight0.35kg
    Color Temperature9500K—11500K
    Horizontal Viewing Angle140º
    Vertical Viewing Angle140º
    Signal Processing10 or 14bit
    The Opposite Calibration CurveWith Eight Optional Gamma Calibration Curve
    Users can choose the recommended curve or adjust it based on actual situation
    MTBF>50000 hours
    Life Span100,000 Hours
    Operating TemperatureWorking : -20 - 65 ℃
    Storage : -40 - 85 ℃
    Environment Temperature-30℃ to 60℃; humidity Rh10% to 95%
    Remote ControlCan realize remote control and send alarm signal to operators in case of logging failure (Be customized)
    Self-checking TechniqueSelf-inspection, communication test, power test, temperature monitoring (Be customized)
    Operating System PlatformWindowsNT,Windows2000,WindowsXP,Windows7
    Power SupplyAC 110-220V
    Protectionwaterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized)



    Reliability Test


    In order to avoid the potential defects caused in the design and production , we conduct a series of reliability test such as the electronic performance test for the semi-finished products , the anti dust test, the waterproof test , the anticorrosion test( salty spraying test ), the vibration test and thermal shock tester etc. The reliability test for the semi-finished products: Before gluing semi-finished modules , more than 48 hours aging should be made in the high temperature for all the modules , After QC inspection ok then can package itThe reliability test for the finished products.: After assembling finished modules to the led cabinets and simulating the assembly for the whole cabinets , we keep them aging for more than 72 hours , if no defects found , then we will delivery goods to our customers .The waterproof test : During the rainy seasons , the waterproof performance for the outdoor led display is quite important. the performs high-press water spraying as well as against the front cabinet to ensure, if waterproof test in good conditions , therefore , protection rate can reach IP65The anti corrosion test : In order to ensure the reliability of anti corrosion of the PCB and cabinet , hence the salty spraying test must be made during the productions Vibration test : For different kind of screens , in order to ensure the reliability of transportation and moving , therefore , the simulated vibration test must be conducted .The environment test : The real outdoor environment can ensure the effects of display in factory are the same as the spot effects
