Shenzhen Weigu Electronic Technology Co., Ltd. Professional Fine Pitch LED Display Perfect the details of professional standards, service achievements better future!
8 Years
| Ask Lasest Price | |
| Brand Name : | Vegoo |
| Model Number : | VGBP1.9 |
| Certification : | CE/ROHS/FCC/CCC |
| Price : | USD8600-USD8760/Set |
| Payment Terms : | T/T |
| Supply Ability : | 5000sq.m/month |
| Delivery Time : | 25-35 working days |
OEM customized LED pantallas P1.9 globe sphere ball display 0.5m diameter private individual module
INSPECTIONS
Product: RGB full color LED ball screen
Pixel pith: P1.9 mm
LED brand: NationStar
GW: 25kgs
Diameter: 0.5m (Option customized)
Module assembly: Screw fixed
Alternative offer: Dia - 1m/1.5m/2m/3m - P2/P2.8/P4
PRODUCTS FEATURES
Flexible service System
100.000 Lifespan
No Ghosting
Magnetic Modules
High Refresh Rate
High View Angles
High Contrast
Extremely Flat Module
Black LED Smd
Flexible Size Panel / Cabinet
Description:
We are advertising LED display screen manufacturer and global wholesaler of large outdoor and indoor
full color electronic LED matrix display screens, LED signs and LED screens used for mayor advertising
campaigns; placed next to highways, or LED message and video displays for football stadiums, electronic
arrival and departure airport displays signs, LED screen displays for schools or shops and malls to
highlight products and services.
1. Modular LED display screens
2. high brightness LED
3. Long Lifespan
P4 Indoor Full color LED Display Specification:
| Product Name | Specification | ||||||||||
| Pixel Pitch | 1.9mm | ||||||||||
| Pixel Configuration | 1R1G1B/SMD1515 Black lamp | ||||||||||
| Density | 62,500 pixel/m2 | ||||||||||
| Moduel Size(L×W)mm | OEM | ||||||||||
| Cabinet Size(L×W×H)mm | OEM | ||||||||||
| Module Resolution | 64×32 | ||||||||||
| Cabinet Resolution | 128×128 | ||||||||||
| Driving Method | 1/16 Scan | ||||||||||
| Driving IC | MBI5124 or ICN 2038S | ||||||||||
| Brightness | 1000cd/㎡ | ||||||||||
| Contrast | 1000:1 | ||||||||||
| Brightness Adjustment | Auto and Manual | ||||||||||
| Power Consumption | Max Power:＜610W | ||||||||||
| Average power: ＜240W | |||||||||||
| Module Weight | 0.2kg | ||||||||||
| Color Temperature | 9500K—11500K | ||||||||||
| Horizontal Viewing Angle | 140º | ||||||||||
| Vertical Viewing Angle | 140º | ||||||||||
| Signal Processing | 10 or 14bit | ||||||||||
| Grey Processing | 1024×1024×1024 16834×16834×16834 | ||||||||||
| Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
| Frame Frequency | 65 Hz | ||||||||||
| Refresh Rate | >1920Hz,3840 | ||||||||||
| Control Mode | Synchronous/Asynchronous | ||||||||||
| The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
| Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
| MTBF | >50000 hours | ||||||||||
| Life Span | 100,000 Hours | ||||||||||
| Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
| Storage : -40 - 85 ℃ | |||||||||||
| Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
| Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
| Power Supply | AC 110–220V | ||||||||||
Applications:
Indoor advertising media, sports stadiums, airport station integrated information dissemination, business
establishments, public area.
Company Introduction
Our products WeiGu LED displays in the rapidly expanding Chinese
market at the same time, has towards the international market, and
the share of export gradually increasing. (all of our products
passed RoHS/CCC/CE/EMC/ISO /FCC certifications. The LED application
product variety is complete which researched and manufactured by
our company, the product structure diversifying. Including: Cover
the indoor and outdoor series. Such like: 1. Rental display; 2.
Advertising LED display; 3. LED TV; 4. Full color anomalous display
etc. Products are widely used in various public places: Such as
commercial plaza, government agency, stadiums, transport
facilities, financial institutions, theater, performance hall, etc.
Our products are exported to the United States, Europe, southeast
Asia and other countries, Hong Kong, Taiwan and other regions. With
international standards of production process, strictly control
product quality and won the customer consistent high praise.
Through the ways like cooperation with local customers, set up
offices in local, WeiGu LED have set up a batch of after-sales
service which can rapidly solve problems. For rapid response, to
quickly solve customer problem, personalized solutions. Make the
products and services reflect personalized, comprehensive, long
cycle, less defects. WeiGu LED is located in Shiyan Town, Baoan
district, Shenzhen. Positive response national green environmental
protection, energy conservation and emission reduction policy in
developing process. We continue to focus on the LED display,
striving to become the world's highest cost-effective LED supplier,
the solution to the overall service, with the attitude of a new
high-speed development in LED display industry.
Fast Contact:
Sales Manager, Lady Seven
Whatsapp: 86-18991939231
|
|
