    Perimeter Football Basketball P10 100m Outdoor Full Color LED Display

    Ask Lasest Price
    Brand Name : Vegoo
    Model Number : VG-P10-DH-ST
    Certification : CE
    Payment Terms : T/T
    Supply Ability : 3000sqm/month
    Delivery Time : 10-20 days
    Price : negotiable
    • Product Details
    • Company Profile

    Perimeter Football Basketball P10 100m Outdoor Full Color LED Display

    P10 Perimeter Outdoor Waterproof Football Basketball Stadium Led Display Screen

    Product Description

    1.High bright 3 in 1 LED SMD lamps with best plastic package suite are not easy to be damaged and ensures the best viewing angle.
    2.Constant current chip driving reduces the power consumption and prompts the stability, the Simple modular design is low cost and easy to maintain.
    3.Can undertake single point, single lamp maintenance,the cost is low.
    4.Neat appearance,light weight,small size and safe 5V low voltage power supply system all make the module more attractive.
    5.Due to its locating holes and 4 in bracket design,it can be used on indoor big screen.
    6.Besides,high definition effect comes with uniform luminance and soft color is suitable for indoor close-range viewing.

    7.Temperature: −20℃~+50℃.Humidity:≤90%.MTBF:≥10,000 hours.
    Lifespan:≥50,000 hours.Defective Dot Rate: <0.0002.


    Different options:

    Standard (1) : Led Lamp + Chip + IC Board + Power supply + Control System + Processor
    Medium (2) : Standard (1) + Installation Solution
    High class (3) : Medium (2) + Installation Solution + Site construction.


    Specification:


    P10 Football Stadium Perimeter Led Banner Display Screen
    Item
    Parameter
    Pixel Pitch
    10mm(H*V)
    Color
    10,000 dots/m2
    LED Shape
    SMD3535
    LED Configuration
    1R1G1B
    Module Size
    320x160mm
    Module Resolution
    32 (W)×16 (H)pixels
    Driving Mode
    1/4Scan,constant current
    Cabinet Material
    Steel
    Brightness
    ≥7200cd/m2
    Contrast
    2000:1
    View Angle
    140°(horz.), 140° (vert.)
    Protection Level
    720 W/sq.m
    Average Power Consumption
    320 W/sq.m
    Viewing distance
    10-100m
    Gray Scale
    12-16bits for red,green,blue
    Colors
    16.7 M
    Input voltage (AC)
    110V ~ 240V
    Frame Frequency
    50Hz-75Hz
    Refresh Rate
    ≥1200Hz
    Brightness Adjustment
    0-100%
    Operating Temperature
    ( -30℃~+50℃ )
    Operating Humidity
    10-90% RH
    Life Span
    100,000Hours
    MTBF
    ≥10,000Hours
    Protection Rating
    IP65 waterproof
    Optional Connectivity
    3/4 G, Wifi control,TCP/IP(LAN)
    Control Method
    Asynchronous or Synchronous
    Controller Type
    LED Editor software

    FAQ

    1. How long could I receive the inquiry reply?
    A: You will get a reply within 24 hours.


    2. How long do you provide warranty time?
    A: Different product offer different time frame warranty, but all product here we offer 2 years at least warranty

    3. How long will it take to deliver goods?
    A: We will start preparing goods when we get your bank receipt. The package will be shipped out in 1-2 working days after we get your payment.

    4. What about your pre-sale service and post-sale service?
    A: For pre-sale service: We have a professional sales team and a 12 years technical team who are willing to answer your question 24/7. We can offer a whole complete solution for your project!
    For post-sale service: We can instruct you how to use, adjust the screens, and change the broken modules with spare parts. Also, we can send technicals to your country to solve problems. Mostly, our led display will not have big problems within warranty time!

    5. How can you ensure the led display product quality?
    A: Our led display screen quality is our core competence, for 12 years, what we rely on. We have each standard process to make quality products.
