    Full Color Small Pitch P1.25 160×120 LED TV Displays

    Ask Lasest Price
    Brand Name : Vegoo
    Model Number : VG-dh-3
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 8000sqm/month
    Delivery Time : 10-20 days
    • Product Details
    • Company Profile

    Full Color Small Pitch P1.25 160×120 LED TV Displays

    Product Description

    1) Super small pixel pitch, show ultra hd image and video for advertising and rental market;

    2) High precision and best quality LED and Drivers, high refresh rate, high grey level;

    3) Small panel, one panel one receiving card, easy to operate and move;

    4) Die Cast Aluminum Cabinet, durable and won't deform;

    5) Support Different Input and output signals.


    P1.25 Indoor Full color LED Display Specification
    NO:Product NameSpecification
    1Pixel Pitch1.25 mm
    2Pixel Configuration1R1G1B/SMD1010 Black lamp
    3Density640,000 pixel/m2
    4Moduel Size(L×W)mm200mm×150mm×8mm
    5Cabinet Size(L×W×H)mm400mm×300mm×60mm
    6Module Resolution160×120
    7Cabinet Resolution320×240
    8Driving Method1/30 Scan
    9Driving ICMBI5153/ICN 2153/FM6353
    10Brightness600-800CD/㎡
    11Contrast4000 :1
    12Brightness AdjustmentAuto and Manual
    13Power ConsumptionMax Power:<900W
    14Average power: <100-300W
    15Cabinet Weight4.2kg
    16Color Temperature2000K—9500K
    17Horizontal Viewing Angle140º
    18Vertical Viewing Angle140º
    19Signal Processing16bit
    20Grey Processing1024×1024×1024
    16834×16834×16834
    21Control Distancecable100m,Multimode500m,Single mode 2km
    22Frame Frequency65 Hz
    23Refresh Rate>3840Hz
    24Control ModeSynchronous/Asynchronous
    25The Opposite Calibration CurveWith Eight Optional Gamma Calibration Curve
    26Users can choose the recommended curve or adjust it based on actual situation
    27MTBF>50000 hours
    28Life Span100,000 Hours
    29Operating TemperatureWorking : -10 - 60 ℃
    30Storage : -40 - 85 ℃
    31Environment Temperature-10℃ to 60℃; humidity Rh10% to 90%
    32Remote ControlCan realize remote control and send alarm signal to operators in case of logging failure (Be customized)
    33Self-checking TechniqueSelf-inspection, communication test, power test, temperature monitoring (Be customized)
    34Operating System PlatformWindowsXP/7/8/10
    35Power SupplyAC110-240V / 5V60Hz
    36Protection Level

    IP 45


    Shenzhen Leader Optoelectronis Technology Co., LTD.
    Shenzhen WeiGu Electronic technology Co., Ltd. is a manufacturer for led displays, with an area of 3000 m² and more than 200 employees.Our products cover all led display models in full color, monochrome and dual color for indoor or outdoor usage. Offering you the service from manufacuring to after-sales warranty.


    Our service
    1.Your inquiry about our productions or prices will be replied in 24hrs.
    2. Well trained and experienced staff answer your question in fluent English.
    3. Both OEM and ODM are avaible. We can help you to design and put that into products.
    4. Offering you the reasonable price and proper shipping method according to your reuiqrement.
    5. Your goods tracking will be updated to your in time.
    6. Purachasing situation, contacts and other important information about buyers will be confidential.
