Brand Name : | Vegoo |
Model Number : | VG-P5.95-DH |
Certification : | CE |
Price : | $580 |
Payment Terms : | T/T |
Supply Ability : | 8000sqm/month |
Delivery Time : | 10-20 days |
Outdoor Large Size Advertising Screen Full Color Led Display Modules P5.95 SMD2727 LED Billboard Prices For Rental
Features:
1. Easy to install
2. Light weight and slim
3. Good heat dissipation
4. High and adjustable brightness
5. Power saving compared with common products
6. Using high reflesh IC, better viewing effect
7. Larger viewing angle: Horizontal angle 140 degree/elevation
angle 140 degree
P5.95 Outdoor Full color LED Display Specification | ||||||||||||
NO: | Product Name | Specification | ||||||||||
1 | Pixel Pitch | 5.95mm | ||||||||||
2 | Pixel Configuration | 1R1G1B/SMD2727 | ||||||||||
3 | Density | 28,235 pixel/m2 | ||||||||||
4 | Moduel Size(L×W)mm | 250mm×250mm | ||||||||||
5 | Cabinet Size(L×W×H)mm | 500mm×500mm×90mm | ||||||||||
6 | Module Resolution | 42×42 | ||||||||||
7 | Cabinet Resolution | 84×84 | ||||||||||
8 | Driving Method | 1/7 Scan | ||||||||||
9 | Driving IC | MBI5124 | ||||||||||
10 | Brightness | 6000cd/㎡ | ||||||||||
11 | Contrast | 6000 :1 | ||||||||||
12 | Brightness Adjustment | Auto and Manual | ||||||||||
13 | Power Consumption | Max Power:<640W | ||||||||||
14 | Average power: <320W | |||||||||||
15 | Cabinet Weight | 11.5kg | ||||||||||
16 | Color Temperature | 2000K—9500K | ||||||||||
17 | Horizontal Viewing Angle | 140º | ||||||||||
18 | Vertical Viewing Angle | 140º | ||||||||||
19 | Signal Processing | 16bit | ||||||||||
20 | Grey Processing | 1024×1024×1024 16834×16834×16834 | ||||||||||
21 | Control Distance | cable100m,Multimode500m,Single mode 2km | ||||||||||
22 | Frame Frequency | 65 Hz | ||||||||||
23 | Refresh Rate | >1920Hz | ||||||||||
24 | Control Mode | Synchronous/Asynchronous | ||||||||||
25 | The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve | ||||||||||
26 | Users can choose the recommended curve or adjust it based on actual situation | |||||||||||
27 | MTBF | >50000 hours | ||||||||||
28 | Life Span | 100,000 Hours | ||||||||||
29 | Operating Temperature | Working : -20 - 65 ℃ | ||||||||||
30 | Storage : -40 - 85 ℃ | |||||||||||
31 | Environment Temperature | -30℃ to 60℃; humidity Rh10% to 95% | ||||||||||
32 | Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) | ||||||||||
33 | Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) | ||||||||||
34 | Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 | ||||||||||
35 | Power Supply | AC 110-220V/5V60Hz | ||||||||||
36 | Protection | waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized) |
Product Aplication
Q1:How to choose a proper led screen for your need?
A:You just need to think of 3 simple questions when you choose a led
screen by yourself.
1.Will you use it indoor or outdoor?
2.Is it for rental use(need to be moved from one place to another
place very often) or for fixed installation(to be installed in one
place forever)?
3.what is the appoximate size of the led screen you would like to
purchase?
Q2:Which pixel pitch should i choose?
A:There are many different pixel pitch from 1.667--20,25,30mm, there
is a roughly principle-usually small pixel(1.667mm-10mm) used for
indoor led screen, bigger pixel (10mm-30mm) used for outdoor led
screen(for example high way huge advertisement).
Q3:Which control system should i choose?
A:There is both synchronous and asynchronous control system for led
screen on the market,for big size led screen(usually more than
20sqm) need to use synchronous control system,below 20sqm it's up
to you to use syn or asyn.But asyn control system's refresh rate is much lower than sync
control system and for asyn control system, you can choose to use wifi,3G,4G etc
wireless control.
Q4:How to order from your compamy?
A:Please send us your purchase order by Email, Whatsapp, Skype,
Facebook or making a call, and we will send you PI as your
approval. Please let us know the follormwing infoation for your order.
Q5:How to pay?
A:T/T and L/C, 30% deposit in advance, and balance 70% before
shipment.
Q6:How to ship?
A:It denpens on your budget and time you need the led screen.
Regularly, if the quantity is less, we suggest to deliver by air,otherwise by sea to save the costs..
Q7:How to install it after i received it?
A:We will offer you the drawing to guide you for installation, we
could also offer steel drawing, software set up drawing or photo or
send our engineer fly to you for help if needed.
![]() |
